Field card 014, Luma x20 IP camera: OPEN UTILITY PORT (2 SCREWS), HOLD RESET 30 s · RELEASE, WAIT · CAMERA RESTARTS, NVR POE PORT › OVRC ACTIVATES IT
A4 · PDF · prints in black and white Open full size
LumaFactory resetCard 014

Luma x20 IP camera

Factory reset and activate on the NVR / OvrC

Bench check pending

Written from official documentation and dealer sources, not yet run on our bench. Confirm on your hardware before a reset you can't undo.

The sequence

  1. OPEN UTILITY PORT (2 SCREWS)
  2. HOLD RESET 30 s · RELEASE
  3. WAIT · CAMERA RESTARTS
  4. NVR POE PORT › OVRC ACTIVATES IT

Good to know

  • NO DEFAULT PASSWORD · OVRC SETS IT
  • Replace the utility port cover
